1/4 CMOS 800TVL HD WDR Color Zoom Module Camera

800TVL HD CMOS Camera Features:

* 1/4" CMOS image sensor
* WDR, Digital noise reduction , Light suppression
* Digital high speed focus, continuous track
* Super low illumination and power consumption.

HD CMOS Camera Specifacations:

Model No .	CET800L
Signal model	PAL/NTSC
Image sensor	1/4" CMOS
Effective pixel	1020(H) x 508(V)
Horizontal resolution	800TVL
Minimum illumination	Color:0.01Lux B/W：0.001Lux/0Lux
WDR	Yes
Sync system	Internal sync
Focus length	3.9~85.8mm	3.2~86.4mm	3~90.0mm
Optical focus	22X	27X	30X
Focus	Auto/manual, take high-performance DSP to realize complete digit and ultra-high speed focus function
Gain Control	Auto/Manual
White balance	Auto
Iris	Auto
S/N radio	>60dB(Enhanced)
Electronic shutter	PAL:1/50~1/10000 seconds NTSC:1/60~1/12000 seconds
Video output	1.0Vp-p 75 Ω
Power cut memory restore	Yes
Language	Chinese/English
Screen menu	AWB , Digital noise reduction , Light suppression,Mirror
Control	SONY/LG
Interface mode	Nine -pin connector
Gama modulus	0.45
Power supply	DC12V,90~120mA
Work temperature	-20°C~+70°C
Dimension	W50mmXH58mmXL90mm
Weight	300g
