Description:
Audio Video Supply is proud to offer the Watec WAT-1200CS NTSC, a compact, high-performance cube camera designed for precision imaging in all lighting conditions.
The Watec WAT-1200CS NTSC is an ultra-miniature day/night camera, engineered for versatility and high-quality imaging within a compact 1"x1"x1" enclosure. Featuring a 1/3.2 BSI CMOS sensor, it delivers over 750 TVL resolution, ensuring sharp, clear visuals across a variety of professional applications. Its CS mount design and OSD interface provide customizable settings, allowing for precise image control tailored to specific needs.
Built for performance in challenging lighting conditions, the WAT-1200CS boasts wide dynamic range, 2DNR noise reduction, and ICR mechanical-less day/night functionality. With an ultra-low-light sensitivity of 0.005 lx F1.8 (AGC 54dB), this camera excels in both bright and dim environments, making it ideal for security, surveillance, scientific research, and systems integration.
Looking for a compact, high-performance day/night camera? Audio Video Supply proudly carries the WAT-1200CS NTSC, offering powerful imaging solutions in an ultra-miniature form.
Features:
* Ultra-Compact Design 每 1" x1" x1" cube, perfect for discreet or embedded applications.
* Superior Low-Light Sensitivity 每 Operates at 0.005 lx F1.8 (AGC 54dB) for exceptional clarity in dim conditions.
* Wide Dynamic Range 每 Delivers balanced imaging in high-contrast lighting scenarios.
* Customizable Imaging 每 OSD interface (optional controller required) allows precise fine-tuning.
* Day/Night Functionality 每 ICR mechanical-less day/night mode ensures seamless light adaptation.
Specifications:
* CCD: 1/3.2 inch
* Resolution: 750
* Power: DC+5V 每 +12V
* P-Supply: AD901 1212P5
* Version: NTSC/PAL
* LUX: 0.002
* SNR (S/N): 55dB
* Shutter: 1/60. 1/100, 1/120, 1/125, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/8000, 1/10000, 1/20000, 1/50000, 1/100000.
* CSen/LFno: F1.2
* Dimensions: 26x26x30
|
|
