Description:
Audio Video Supply is the Watec WAT-1100MBD G3.6 NTSC, a powerful miniature day/night camera built for ultra-low-light performance and seamless integration.
The Watec WAT-1100MBD G3.6 NTSC is a compact, high-performance day/night board camera designed for precision imaging in both daylight and near-total darkness. Featuring a 1/3.2 BSI CMOS sensor, it delivers 750 TVL resolution for sharp, true-to-life imaging while maintaining a discreet, low-profile design perfect for covert installations and specialized integrations.
With an ultra-low-light sensitivity of 0.005 lx F1.8 (AGC 54dB), this camera excels in challenging lighting conditions, making it ideal for security, surveillance, and industrial applications. The 3.6mm M12 lens provides precise focus and enhanced clarity, ensuring high-quality imaging across various environments. Bundled with the CB-01 power/video harness and AD901 1212 P5 power supply, the WAT-1100MBD G3.6 NTSC is ready for easy integration right out of the box.
Searching for a high-performance miniature day/night camera? Audio Video Supply proudly carries the WAT-1100MBD G3.6 NTSC, delivering superior low-light imaging for professional applications.
Features:
* Day/Night Functionality 每 High-quality imaging in both bright and ultra-low-light conditions.
* Ultra-Compact Design 每 Miniature size allows for discreet installation and seamless system integration.
* Full-Color HD Video 每 Captures vivid, true-to-life images in multiple resolutions, including 1920℅1080 and 1280℅720.
* High Sensitivity 每 Operates in 0.005 lx F1.8, ensuring clear visuals in near-total darkness.
* Superior Resolution 每 Produces crisp, high-quality imaging with 750 TVL resolution.
* Complete Setup 每 Includes CB-01 harness and AD901 1212 P5 power supply for immediate use.
Specifications:
| Pick-up element |
1/3.2 inch BSI CMOS image sensor |
| Number of effective pixels |
1280(H) ℅ 960(V) |
| Unit cell size |
3.5米m(H)℅3.5米m(V) |
| Imaging system |
RGB+W array mosaic filters on chip |
| Synchronizing system |
Internal |
| Scanning system |
Progressive |
| Video output |
Composite: 1.0 V(p-p) 75次 (Unbalanced) |
| Resolution (H) |
More than 750TVL (Center) |
| Minimum illumination |
0.005 lx F1.8 (AGC=54dB) |
| S/N |
More than 55dB (AGC=OFF﹜ 污=1.0) |
| Function settings |
OSD (On Screen Display) operated by remote controller |
| AE mode |
Fixed: 1/100, 1/120, 1/125, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/8000, 1/10000, 1/20000, 1/50000, 1/100000 sec
EI: 1/60 - 1/100000 sec., 1/50 - 1/100000 sec. |
| White balance |
ATW, PUSH, USER1, USER2, MANUAL, PUSH LOCK |
| AGC |
0 - 54dB |
| MGC |
MIN, 6, 12, 18, 24, 30, 36, 42, 48, MAX dB |
| Day / Night |
ICR mechaless Day/Night |
| Gamma characteristics |
污沌0.45 |
| Noise reduction |
2DNR ON (Level adjustable) |
| Wide dynamic range |
Mutiple exposure WDR: ON (Level selectable) / OFF
ATR : ON (Level selectable) / OFF |
| Lens Iris |
DC |
| Back Light Compensation |
OFF / BLC / HLC |
| Defog |
OFF / AUTO (Correction level selectable) |
| Privacy Mask |
16masks |
| Mirror Image |
OFF / V-FLIP / H-FRIP / HV-FLIP |
| Sharpness |
0 - 255 (SHARPNESS) |
| Power Supply |
DC+5V - 12V |
| Power Consumption |
0.72W (60mA) ↗12V |
| Operating Temperature |
-10 - +50⊥ |
| Storage Temperature |
-30 - +70⊥ |
| Operating / Storage humidity |
95% RH or less (Without condensation) |
| Lens Mount |
M12 P=0.5 |
| Standard Lens |
M3718BC-12ㄗf3.7 F1.8ㄘ |
| Weight |
Approx. 13.5g |
| Accessories |
4P Cable, I/O Cable |
|
|
